Dahtone Racing V2 RB26 ITB Drive By Wire

Dahtone Racing V2 ITB DBW (Individual Throttle Body Drive By Wire) system uses a Bosch based billet aluminium throttle actuator that has built in throttle position sensors.
There is no need for any extra sensors, brackets, wires or connectors, everything functions just like a Bosch single throttle body would.

TPS tracking is perfect and max current draw is under 4 Amps, which means there is no need for any external control boxes or half bridge modules. It will work on any ECU that can run a Bosch drive by wire throttle body.

The system works with any 6 throttle inlet manifold (OEM, Nismo, Plazmaman, Hypertune or even N/A with velocity stacks) without the need for any extra parts, and also fits with the OEM oil cooler/filter block assembly.

Parts Included

• 1 x Bosch based billet aluminium drive by wire actuator
• 1 x New Genuine Nissan throttle linkage
• 1 x Throttle shaft joiner
• 1 x Throttle shaft joiner with integrated linkage arm
• 1 x Throttle actuator arm
• 1 x Throttle actuator plug and pin kit
• 1 x Throttle actuator bracket
• 2 x weld in bungs ( 1/8 npt and 1/4 npt)
• Stainless fasteners
