Radium Aftermarket Configuration Fuel Rail Kit - Lotus (2ZZ-GE)

Radium Aftermarket Configuration Fuel Rail Kit — Lotus 2ZZ-GE

This high-volume billet aluminium fuel rail is designed for all 2ZZ-GE engines, covering both normally aspirated and supercharged Lotus applications. Both ends of the rail are tapped to 8AN ORB female threads, using positive O-ring seals instead of tapered pipe threads — eliminating the risk of damaged aluminium threads and fuel leaks common with NPT fittings.

The centre port accommodates the 2ZZ-GE fuel pulse damper from the OEM fuel rail (not included), helping alleviate high-frequency fuel pressure fluctuations for consistent injector performance. The rail is designed to clear the intercooler mounting boss on Exige-S and 2-Eleven models as best as possible without sacrificing fuel flow — minor grinding may still be required in some cases.

Suits: All Toyota 2ZZ-GE engines — Lotus Elise, Exige, Exige-S, 2-Eleven (supercharged and normally aspirated)

Features:

• Billet aluminium construction with anodized surface finish for corrosion resistance
• Stealth laser-etched logos applied pre-anodizing
• End ports: 3/4-16 female thread (-8AN ORB)
• Compatible with factory and aftermarket injectors
• Easily converted to a pressure-regulated return system
• Fits under the factory fuel rail cover
• Supercharged Lotus intercooler boss remains functional

Kit Includes:

• Billet aluminium 2ZZ-GE fuel rail
• Mounting hardware
• OEM fuel pulse damper bracket and associated screws

Note: No fittings are included. Fuel pulse damper is not included.

Available Part Numbers:

• 20-0012-01 — Fuel Rail Kit, Toyota 2ZZ-GE (Lotus Elise/Exige)

Why Radium Engineering?

• ✅ Manufactured in the USA to motorsport-grade tolerances
• ✅ CNC-machined billet aluminium for precision fit and long-term durability
• ✅ Trusted by tuners and race teams running high-power Lotus 2ZZ-GE builds worldwide
• ✅ O-ring sealed -8AN ORB ports — no tapered threads, no fuel leaks
• ✅ Compatible with OEM and aftermarket injectors; supports return-style fuel system conversion
